JET Filters: Guaranteed Freedom from Dust

The NESTRO jet filter is used as an intermediate filter to remove various dusts. It may be used on either the clean gas or the raw gas side and is the perfect solution for 24/7 operation.
The modular element design allows the length to be configured in stages (1,180 mm) while the width remains the same (2,400 mm). The fully-automatic valve control with controller guarantees the optimal regeneration of the filter system. Cleaning is performed depending on the differential pressure, which reduces the compressed air consumption to a minimum.

Structure of a jet filter

The filter unit consists of filter plate, filter hoses or filter cartridges and pre-separation chamber. Depending on type and length, the filter area is 74 to 144 m² per element. The choice of filter media is determined by the material to be conveyed and by the exhaust and exhaust air routing. The limit values of the TA-Luft are safely adhered to.

Stability, Protection and Easy Handling

The weatherproof casing protects the filter system against the elements. It also serves as a structural element for hose suspension. The layout and structure permit targeted exhaust and outgoing air flow routeing along with negative pressure operation of the system. Safe and straightforward access to all parts of the system is assured. This minimises service costs.

3D Product Viewer

Intermediate Filters 9/4 S

Screw conveyor

Data Sheet Intermediate Filters - DE EN FR

By loading the datasheet you accept issuu's privacy policy.

Learn more

Data Sheet Intermediate Filters NFP - DE EN FR

By loading the datasheet you accept the issuu privacy policy.

Learn more



By loading the flyer you accept issuu's privacy policy.

Learn more

System Documentation
NESTRO supplies you with an extensive system documentation (operating instructions, drawings, wiring diagram etc.) in the language of your country.
